LIFTMASTER INDUSTRIAL 24V DC "SLIDING" GATE OPERATOR (70'/2200 LBS)

PLEASE NOTE: A TARIFF FEE WILL BE ADDED TO THIS ITEM AT CHECKOUT ***

Operator comes with brackets only, no posts.

*** Included Accessories ***

• LMRRUL -Monitored Retro Reflective Photo Eye. Reliable retro-reflective photo eye now with heater and wide beam, engineered to stay aligned; max. Range: 50 ft.
• LMS505AL -Monitored Small Profile resistive edge. Pressure-sensitive edge senses obstructions.

Reliable

• Move Industrial gates up to 2,200 lbs. at 1 ft./sec.
• Continuous-duty gate operation built with a custom industrial oil-bath gear box
• Custom Industrial brushless DC motor
• Enclosure Lockable, Weatherproof 14g NEMA 3R Steel Cabinet
• Variable cycle speed adjusts to meet application needs from .5 ft./sec. to 1 ft./sec.
• Smooth start/stop operation and mid-travel reversal extend operator hardware life.
• #50 industrial chain provides a pull strength of 2x the gate weight.
• Manual Disconnect with direct mechanical linkage with latch

Smart:

• Powered by myQ® for full insight and control over community and facility access points. Improve warehouse efficiency and productivity with Smart Facility Access.* Monitor and control multiple communities with Smart Community Access.
• Two programmable auxiliary relays accommodate more accessories.
• Wireless dual-gate communication synchronizes gate operation and eliminates costly trenching; set speed independently if needed.

Safe and Secure:

• Quick close and anti-tailgate quickly secures property, preventing unauthorized access.
• Posilock® automatically closes the gate when it is pushed from the closed limit.
• UL® listed gate operator with monitored safety entrapment protection devices.

Mechanics:

• 24VDC brushless continuous-duty motor
• Operator Duty Rating: high-cycle, high-temperature continuous duty
• Direct Drive
• Chain: #40 Industrial

Power:

• 120/240V single-phase
• Accessory Power: 24VDC 1 A max. output; switched and unswitched power
• Solar-Ready, Ultra-Reliable System delivers power when and where you need it (LMRRUL/LMTBUL - heater option not recommended for solar applications).

Industrial Grade Design

• Chassis: Constructed with 1/4 in. Steel, Powder Coated
• Housing: powder-coated, 14-gauge steel oil -tight, weatherproof NEMA 3R lockable cabinet
• UL® Usage Classification: II, III, and IV
• Operator Weight: 129 lbs.

Dimensions

• Height: 30.1”
• Width: 27.5”
• Depth: 17.1”

Variable Gate Speed:

• .5 ft to 1 ft. per second

Standard Features:

• Inherent Reversing Sensor detects obstructions and reverses gate.
• Manual Disconnect allows gate to be opened manually when released.
• Monitored Safety Inputs 3 main board, 3 expansion board.
• Security+ 2.0® On-Board Radio Receiver:
  up to 50 remote controls (unlimited with 811LMX/813LMX).
• LED Diagnostic Display simplifies installation and troubleshooting
• Programmable Auxiliary Relays: 2 relays make adding additional features easy.
