FAIL SAFE, back drivable manual operation upon loss of AC power or battery.
- Motor Type: 1-1/4 HP 24V Brushless DC - 6 Mil Cycles
- Max Gate Weight: 1800 lbs
- Duty Cycles: Continuous
- Max Gate Length: 40 ft
- Gate Speed: 12" Per Second
- Motor Safety: Motor Overcurrent Safety Shut-Off
- Power Options: Switchable 115/230 VAC
- Battery Back Up: Built-in; Providing a Minimum of 100 Cycles
- Temperature Range: -4ºF to 165ºF (-20ºC to +74ºC)
- Heavy Duty Direct Drive Gearbox: Size 60, 20:1 Gear Ratio - Direct Gear Drive (Cast Iron Housing)
- Dimensions:15" W x 19" D x 25-3/4" H
- Shipping Weight: 138 lbs
- Emergency Release: Mechanical Release: Local Switch, Keypad, or Any Dry Contact Relay & Via Max App
- Chain Size: #50 Nickel Plated Included
- Breaker: 20 amp Dedicated
- Power Outputs: Built-in 12VDC and 24VDC
